Specification
|
overall weight(kg)
|
3200
|
|
L×W×H（mm）
|
4760×1680×2550
|
|
rated bucket capacity(m3)
|
0.7
|
|
Rated load(kg)
|
1500
|
|
Maximum dump height (mm)
|
2750
|
|
Bucket indicator
|
Yes
|
|
Max. breakout force(KN)
|
43
|
|
Engine
|
Model
|
Xinchai A498BT1(EURO III)
|
|
Type
|
In-line arrangement, Water cooling, four-stroke
|
|
Rated power（kw）
|
36.8kw
|
|
Rated speed(r/min)
|
2200
|
|
Transmission system
|
Model of torque converter
|
YJ240
|
|
Type
|
single-phase single-stage radial-inward turbine triplex
|
|
Gearbox type
|
Fixed-spindle power shift
|
|
Gear shift
|
2 gears ahead,2 gear astern
|
|
Hydraulic system
|
Distribution of work valve
|
ZL20B
|
|
Working pump
|
CBGj1045,CBGq1018
|
|
Steering system
|
Type
|
Articulated hydraulic steering
|
|
Max. turning angle
|
27±1°
|
|
Min turning radius(mm)
|
3000
|
|
Brake system
|
Brake type
|
Oil brake(Vacuum booster)
|
|
Tyres
|
Standard tyres
|
12-16.5
|
|
Optional wide tyres
|
14-17.5
|
